Just as the name suggested, the drum chipper is mainly on the application of pellet mill production plant lines to process wood logs, square blocks, and wood staff and so on. However, the drum chipper is an ideal equipment to help customers handle wood block or logs. What’s more, this machine is widely used in paper plants, flake board plants and fiber-board factory. It can cut wood logs and blocks into high quality chips of even length and uniform chip thickness. The drum chipper machine is made up of high strength steel plates which make sure increase durability. The knives are connected to the rotor by a clamping plant. In addition, the upper faced roller assembly can float up and down over the material to be cut within certain range according to the thickness of raw materials. Therefore these virtues make our drum chipper ideal for chip production for markets all over the world.
Technical Parameters for Drum Chipper Machine:
| Model | BX213 | BX215 | BX216 |
| Rotor Diameter(mm) | 300 | 500 | 650 |
| Number of rotor knives(pieces) | 2 | 2 | 2 |
| Feed opening(mm) | 120x300 | 180x400 | 240x540 |
| Rotor Speed(Rpm) | 730 | 592 | 590 |
| Feed Speed(m/min) | 38 | 38 | 38 |
| Stock processed max diameter(mm) | 90 | 160 | 200 |
| Chip length(mm) | 26 | 35 | 35 |
| Capacity(m3/h) | 3-5 | 4-5 | 12 |
| Main drive motor power(KW) | 30 | 45 | 55 |
| Feed roller motor power(KW) | 1.1x2 | 2.2x2 | 3x4 4x1 |
| Weight(t) | 1.2 | 2.9 | 4.07 |
| Overall dimensions(LxWxH)(mm) | 3680x870x900 | 1540x1240x1020 | 1980x1950x1250 |
More information and technology questions, welcome to phone us or email after-service support! We are looking forward to hearing from your enquiry!
